The LUXI 350 Series is a complete, universal AV switching and processing unit all in one set of boxes. This unit is a VGA/HDMI/DisplayPort and audio 3x2 universal switcher, scaler, splitter. It also comes with these features - audio de-embedder and embedder, auto switching, display power controls, RS-232, contact closure controls with HDBT output with 24 V POC.

This is a transmitter unit which will need to be paired with a receiver unit.

Specifications

• World's smallest high performance all-format, all-purpose, HDCP compliant signal converter, scaler, switcher, splitter, audio mixer, embedder, de-embedder
• VGA, HDMI, DP input, auto switch or front panel, RS-232, contact controllable
• Automatically turn on display when a signal plugged in, turn off when no signal
• HDBT output for big screen/projector and HDMI output for local monitor/VC
• Analog audio input for laptop or wireless microphone
• Balanced/unbalanced audio outputs for driving power amplifiers
• Send signals to up to 70 m (235’) with Cat 6 cables; POC
• Multiple preset video output formats or pixel to pixel mode
• Selectable audio digitally pass thru or mixing and embedding, or mute
• HDMI 2.0 4k 30 Hz, 21:9 aspect ratio, dynamic AV sync, CEC extensions, 3D, deep color compliance
• High efficiency fanless design, rack mountable, under-table mountable
